The 1029-0007 red pedal position sensor is a contacting rotary-position sensor designed for compatible drive-by-wire throttle and pedal-control applications. It is suitable for selected agricultural, construction, heavy-truck, marine, industrial, and off-highway equipment requiring the corresponding 1029L electrical and mechanical configuration.
The 1029 sensor design uses silver-in-glass encoder technology to convert pedal or control movement into an electrical position signal. Its field-proven construction is intended to provide accurate response and long operating life in demanding equipment environments.
Important: The 1029 family was produced in multiple configurations. Confirm reference number 1029-0007, housing color, connector, pin configuration, mounting arrangement, rotation direction, supply voltage, idle voltage, full-travel voltage, and output relationship before ordering.
Features & Benefits
- Contacting rotary pedal-position sensor
- Designed for compatible drive-by-wire throttle applications
- Silver-in-glass encoder sensing technology
- Designed for accurate and repeatable pedal-position reporting
- Tested sensor-family design for demanding operating environments
- EMC-robust 1029-family architecture
- Red housing for configuration identification
- Suitable for compatible pedal, hand-control, and rotary-position applications
Product Information
-
California Diesel SKU: SEPPS03
-
Primary Reference: 1029-0007
-
Product-Family Reference: 1029L
-
Product Type: Pedal Position Sensor
-
Also Known As: Accelerator Pedal Position Sensor / Rotary Position Sensor
-
Sensor Technology: Contacting Silver-in-Glass Encoder
-
Housing Color: Red
-
Standard: Primary 1029-family configuration conforms to SAE J1834
-
Condition: New and Unused
-
Packaging: Neutral Protective Packaging
Typical Applications
- Agricultural equipment
- Construction equipment
- Heavy-duty trucks
- Marine equipment
- Industrial equipment
- Off-highway vehicles
- Compatible drive-by-wire throttle controls
- Compatible pedal and rotary-position controls
These equipment categories describe typical applications of the configurable 1029 sensor family. They do not confirm direct fitment to a specific vehicle or machine. Match the complete sensor number and electrical configuration before installation.
Reference Numbers
-
1029-0007: Primary sensor reference
-
1029L: Sensor-family and configuration reference
-
SEPPS03: California Diesel SKU
-
VH10693907: California Diesel legacy application reference; verify independently before using as a direct interchange
Brand and Configuration Notice
The 1029 design is associated with Wabash Technologies® sensor literature. This California Diesel listing is for AEPD inventory supplied in neutral packaging. It should not be represented as a genuine Wabash-branded product unless the physical sensor markings or supplier documentation independently confirm the manufacturer.
The SAE J1834 conformity statement applies to the primary 1029-family configuration. Because customer-specific electrical and mechanical variations were available, verify the actual 1029-0007 configuration before installation.
AEPD Inventory Disclosure
This item is new and unused AEPD inventory. Due to warehouse storage and handling, the component or its packaging may show minor cosmetic marks, surface discoloration, shelf wear, label wear, or other evidence of prior handling. These cosmetic conditions do not affect the product’s intended function. Supplied in neutral protective packaging unless otherwise shown.
Installation and Calibration
Installation should be completed by a qualified technician. Before connecting the sensor, compare its connector, terminal functions, mounting dimensions, operating direction, supply voltage, idle-position voltage, and full-travel output with the original component and equipment service information.
An incorrect output configuration can cause inaccurate throttle-position reporting, diagnostic trouble codes, reduced engine response, or improper throttle operation.
